Minion Style CMF Phone 2 Pro Cover with Stand and compatible with MagSafe accessories

Stuart from Minions is joining the Nothing family! Inspired by Stuart in black suit.

Note: This model was printed with 0.6 nozzle, which is the only one I have, but it should also work with 0.4 nozzle. I had access to grey PETG, yellow and orange PLA, but either type of filament should work for this model.

Features:

• 360° adjustable ring stand
• MagSafe accessory compatible using nicked ESR Magsafe Ring
• Stay-flat design: flush with camera bump - no wobble!
• Printed without support
• Modular assembly
  1. Connecting ring in yellow for Stuart's eye: Stuart's eye-white portion prints in the same yellow filament, but at only a layer of 0.2mm to differentiate from eyelid. Pupil is manually colored black with a Sharpie to avoid a 3rd filament color. The iris is not printed and uses the phone backpanel color.
  2. CMF case with color-change (or without!): a custom G-code with color-change M600 inserted within the first layer is available (in 0.6n!). Stuart's tie and suit are manually colored black with a Sharpie to avoid a 3rd filament color. Stuart's shirt is printed as 90% grid to mimic fabric.
  3. CMF original lens cover in grey to mimic metallic goggle frame.
  4. Ring stand with filament hinge in grey.

Assembly:

1. Print CMF original lens cover and ring stand in grey.  Insert filament into both hinges (circled in yellow). 2a. Heat can be optionally applied to fix the filament into hinge. 2b. If ring stand with MagSafe slot is printed, press in the ESR MagSafe Ring (orange dashed lines).

   .

2. Print connecting ring and CMF case with or without color change.



3. Remove thumb screw from CMF case. Resort to an Xacto knife as needed.



4. Press Connecting ring (thin pupil layer facing you) into CMF case (Stuart facing up).



5. Press Ring stand onto the Connecting ring in any orientation.



6. Press lens cover into CMF case.



7. Sharpie over the iris, suit, or any area you see fit.



8. Install CMF case onto your CMF Phone 2 Pro (if you have one).
